阿普奇ATX主板ATT-H31C是一款功能全面、性能卓越的工業級主板,適用于各種需要高效穩定運行的場景。它支持Intel? 6~9th Gen Core/Pentium/Celeron處理器,提供穩定高效的運算體驗。ATT-H31C配備2個DDR4-2666MHz內存插槽,最高可擴展至64GB,滿足大數據處理需求。高速網絡連接通過2個Intel千兆網卡實現,確保穩定、高速的數據傳輸。串口和USB接口豐富,包括2個RS232/422/485、4個RS232以及4個USB3.2和5個USB2.0,方便各種外設連接。顯示接口提供HDMI、DVI、VGA和eDP,支持最高4K@30Hz分辨率,呈現清晰畫質。擴展插槽包括1個PCIe x16、1個PCIe x4和5個PCI,方便擴展卡接入。
阿普奇ATT-H31C工業主板為用戶提供了強大的處理能力、高速的網絡連接、豐富的串口和USB接口以及高質量的顯示效果,是用戶進行各種應用開發、系統集成和升級的理想選擇。
Model | ATT-H31C | |
ProcessorSystem | CPU | Support Intel??6/7/8/9th Generation Core / Pentium/ Celeron Desktop CPU |
TDP | 65W | |
Socket | LGA1151 | |
Chipset | H310C | |
BIOS | AMI 256 Mbit SPI | |
Memory | Socket | 2 * Non-ECC U-DIMM Slot, Dual Channel DDR4 up to 2666MHz |
Capacity | 64GB,?Single Max. 32GB | |
Graphics | Controller | Intel??HD Graphics |
Ethernet | Controller | 1 * Intel i210-AT GbE LAN Chip (10/100/1000 Mbps)?1 * Intel i219-LM/V GbE LAN Chip (10/100/1000 Mbps) |
Storage | SATA | 3 * SATA3.0 7P Connector, up to 600MB/s |
M.2 | 1 * M.2 Key-M (SATA3.0, 2242/2260/2280) | |
Expansion Slots | PCIe slot | 1 * PCIe x16 slot (Gen 3, x16 signal)1 * PCIe x4 slot (Gen 2, x4 signal, Default, co-lay with?Mini PCIe) |
PCI | 5 * PCI slot | |
Mini PCIe | 1 * Mini PCIe (PCIe x1 Gen 2 + USB2.0 (Opt., co-lay with?PCIe x4 slot), with 1 * SIM Card) | |
Rear I/O | Ethernet | 2 * RJ45 |
USB | 4 * USB3.2 Gen 1x1 (Type-A, 5Gbps,?Each group of two ports Max. 3A, one port Max. 2.5A)2 * USB2.0 (Type-A,?Each group of two ports Max. 3A, one port Max. 2.5A) | |
PS/2 | 1 * PS/2 (Keyboard & Mouse) | |
Display | 1 * DVI-D: max resolution up to 1920*1200 @ 60Hz1 * HDMI1.4: max resolution up to 3840*2160 @ 30Hz | |
Audio | 3 * 3.5mm Jack (Line-out + Line-in + MIC) | |
Serial | 2 * RS232/422/485 (COM1/2, DB9/M, Full Lanes, BIOS Switch) | |
Internal I/O | USB | 1 * USB2.0 (Vertical Type-A)2 * USB2.0 (Header) |
Display | 1 * VGA: max resolution up to 1920*1200 @ 60Hz (wafer)1 * eDP: max resolution up to 1920*1200 @ 60Hz (Header) | |
Audio | 1 * Front Audio (Line-Out + MIC, Header)1 * Speaker (3W (per channel) into a 4Ω Loads, wafer) | |
Serial | 4 * RS232 (COM3/4/5/6, Header, Full Lanes) | |
GPIO | 1 * 16 bits DIO (8xDI and 8xDO, wafer) | |
LPT | 1 * LPT (Header) | |
SMBus | 1 * SMBus (wafer) | |
SATA | 3 * SATA3.0 7P Connector | |
FAN | 1 * CPU FAN (Header)2 * SYS FAN (Header) | |
Front Panel | 1 * Front Panel (Header) | |
Power Supply | Type | ATX |
Connector | 1 * 8P 12V Power (Header)1 * 24P Power (Header) | |
OS Support | Windows | 6/7th Core?: Windows 7/10/118/9th Core?: Windows 10/11 |
Linux | Linux | |
Watchdog | Output | System Reset |
Interval | Programmable 1 ~ 255 sec | |
Mechanical | Dimensions | 304.8 x 243.8 mm (12" x 9.6") |
Environment | Operating Temperature | -20 ~ 60℃ (Industrial SSD) |
Storage Temperature | -40 ~ 80℃ (Industrial SSD) | |
Relative Humidity | 10 to 95% RH (non-condensing) |
